R58減速機傳動比計算：齒輪減速馬達

輸送帶參數：輪子直徑120，負載2.5噸，一分鐘走30米

30米÷（0.12輪子直徑×3.14）=79.6轉每分鐘

2.5噸換算成N=25000N

25000×0.06輪子半徑×0.06摩擦系數=90N.m

通常確保萬無一失，我們會把輸出扭矩放大兩倍90×2=180N.m

電機轉數1400÷輸出轉數79.6=17.58比

180N.m輸出扭矩÷17.58比=10.23N.m電機扭矩

10.23N.m電機扭矩換算成功率1.52KW以上

對應的R58減速機選型參數：

型號：R58-B1.5KW

減速比：18.60

輸出轉數：77轉每分鐘

輸出扭矩：186N.m

安全系數：2.40

R58減速機平面圖紙：輸出軸Φ20+鍵2.5（可定做），高134*寬135*長174（帶輸出軸）R系列減速機

R58臥式硬齒面斜齒輪減速機型號：

R57FDM100L4,R57FDM100LC4,R57FDM100LS4,R57FDM100M4,R57FDM112M4,R57FDM132L4,R57FDM132M4,R57FDM132MC4,R57FDM132ML4,R57FDM132S4,R57FDM63L4,R57FDM63M4,R57FDM63MS4,R57FDM63S4,R57FDM71D4,R57FDM71M4,R57FDM71MS4,R57FDM71S4,R57FDM80K4,R57FDM80M4,R57FDM80MK4,R57FDM80N4,R57FDM80S4,R57FDM90L4,R57FDM90M4,R57FDM90S4,R57FDR100L4,R57FDR100LC4,R57FDR100LS4,R57FDR100M4,R57FDR112M4,R57FDR132L4,R57FDR132M4,R57FDR132MC4,R57FDR132ML4,R57FDR132S4,R57FDR63L4,R57FDR63M4,R57FDR63MS4,R57FDR63S4,R57FDR71D4,R57FDR71M4,R57FDR71MS4,R57FDR71S4,R57FDR80K4,R57FDR80M4,R57FDR80MK4,R57FDR80N4,R57FDR80S4,R57FDR90L4,R57FDR90M4,R57FDR90S4,R57FDRE100L4,R57FDRE100LC4,R57FDRE100LS4,R57FDRE100M4,R57FDRE112M4,R57FDRE132L4,R57FDRE132M4,R57FDRE132MC4,R57FDRE132ML4,R57FDRE132S4,R57FDRE63L4,R57FDRE63M4,R57FDRE63MS4,R57FDRE63S4,R57FDRE71D4,R57FDRE71M4,R57FDRE71MS4,R57FDRE71S4,R57FDRE80K4,R57FDRE80M4,R57FDRE80MK4,R57FDRE80N4,R57FDRE80S4,R57FDRE90L4,R57FDRE90M4,R57FDRE90S4,R57FDRN100L4,R57FDRN100LC4,R57FDRN100LS4,R57FDRN100M4,R57FDRN112M4,R57FDRN132L4,R57FDRN132M4,R57FDRN132MC4,R57FDRN132ML4,R57FDRN132S4,R57FDRN63L4,R57FDRN63M4,R57FDRN63MS4,R57FDRN63S4,R57FDRN71D4,R57FDRN71M4,R57FDRN71MS4,R57FDRN71S4,R57FDRN80K4,R57FDRN80M4,R57FDRN80MK4,R57FDRN80N4,R57FDRN80S4,R57FDRN90L4,R57FDRN90M4,R57FDRN90S4,R57FDRS100L4,R57FDRS100LC4,R57FDRS100LS4,R57FDRS100M4,R57FDRS112M4,R57FDRS132L4,R57FDRS132M4,R57FDRS132MC4,R57FDRS132ML4,R57FDRS132S4,R57FDRS63L4,R57FDRS63M4,R57FDRS63MS4,R57FDRS63S4,R57FDRS71D4,R57FDRS71M4,R57FDRS71MS4,R57FDRS71S4,R57FDRS80K4,R57FDRS80M4,R57FDRS80MK4,R57FDRS80N4,R57FDRS80S4,R57FDRS90L4,R57FDRS90M4,R57FDRS90S4,R57FDT100L4,R57FDT100LC4,R57FDT100LS4,R57FDT100M4,R57FDT112M4,R57FDT132L4,R57FDT132M4,R57FDT132MC4,R57FDT132ML4,R57FDT132S4,R57FDT63L4,R57FDT63M4,R57FDT63MS4,R57FDT63S4,R57FDT71D4,R57FDT71M4,R57FDT71MS4,R57FDT71S4,R57FDT80K4,R57FDT80M4,R57FDT80MK4,R57FDT80N4,R57FDT80S4,R57FDT90L4,R57FDT90M4,R57FDT90S4,R57FDV100L4,R57FDV100LC4,R57FDV100LS4,R57FDV100M4,R57FDV112M4,R57FDV132L4,R57FDV132M4,R57FDV132MC4,R57FDV132ML4,R57FDV132S4,R57FDV63L4,R57FDV63M4,R57FDV63MS4,R57FDV63S4,R57FDV71D4,R57FDV71M4,R57FDV71MS4,R57FDV71S4,R57FDV80K4,R57FDV80M4,R57FDV80MK4,R57FDV80N4,R57FDV80S4,R57FDV90L4,R57FDV90M4,R57FDV90S4,R57FDVE100L4,R57FDVE100LC4,R57FDVE100LS4,R57FDVE100M4,R57FDVE112M4,R57FDVE132L4,R57FDVE132M4,R57FDVE132MC4,R57FDVE132ML4,R57FDVE132S4,R57FDVE63L4,R57FDVE63M4,R57FDVE63MS4,R57FDVE63S4,R57FDVE71D4,R57FDVE71M4,R57FDVE71MS4,R57FDVE71S4,R57FDVE80K4,R57FDVE80M4,R57FDVE80MK4,R57FDVE80N4,R57FDVE80S4,R57FDVE90L4,R57FDVE90M4,R57FDVE90S4,R57F-Y0.12KW,R57F-Y0.18KW,R57F-Y0.25KW,R57F-Y0.37KW,R57F-Y0.55KW,R57F-Y0.75KW,R57F-Y1.1KW,R57F-Y1.5KW,R57F-Y100M4,R57F-Y112M4,R57F-Y132M4,R57F-Y2.2KW,R57F-Y3KW,R57F-Y4KW,R57F-Y5.5KW,R57F-Y63M4,R57F-Y7.5KW,R57F-Y71M4,R57F-Y80M4,R57F-Y90M4,R57F-YEJ0.12KW,R57F-YEJ0.18KW,R57F-YEJ0.25KW,R57F-YEJ0.37KW,R57F-YEJ0.55KW,R57F-YEJ0.75KW,R57F-YEJ1.1KW,R57F-YEJ1.5KW,R57F-YEJ100M4,R57F-YEJ112M4,R57F-YEJ132M4,R57F-YEJ2.2KW,R57F-YEJ3KW,R57F-YEJ4KW,R57F-YEJ5.5KW,R57F-YEJ63M4,R57F-YEJ7.5KW,R57F-YEJ71M4,R57F-YEJ80M4,R57F-YEJ90M4,R57F-YVP0.12KW,R57F-YVP0.18KW,R57F-YVP0.25KW,R57F-YVP0.37KW,R57F-YVP0.55KW,R57F-YVP0.75KW,R57F-YVP1.1KW,R57F-YVP1.5KW,R57F-YVP100M4,R57F-YVP112M4,R57F-YVP132M4,R57F-YVP2.2KW,R57F-YVP3KW,R57F-YVP4KW,R57F-YVP5.5KW,R57F-YVP63M4,R57F-YVP7.5KW,R57F-YVP71M4,R57F-YVP80M4,R57F-YVP90M4,R57F-YVPEJ0.12KW,R57F-YVPEJ0.18KW,R57F-YVPEJ0.25KW,R57F-YVPEJ0.37KW,R57F-YVPEJ0.55KW,R57F-YVPEJ0.75KW,R57F-YVPEJ1.1KW,R57F-YVPEJ1.5KW,R57F-YVPEJ100M4,R57F-YVPEJ112M4,R57F-YVPEJ132M4,R57F-YVPEJ2.2KW,R57F-YVPEJ3KW,R57F-YVPEJ4KW,R57F-YVPEJ5.5KW,R57F-YVPEJ63M4,R57F-YVPEJ7.5KW,R57F-YVPEJ71M4,R57F-YVPEJ80M4,R57F-YVPEJ90M4。

R57系列減速機參數大全：同軸斜齒輪減速電機

R57F減速機配0.12KW電機參數

R57F減速機配0.18KW電機參數

R57F減速機配0.25KW電機參數

R57F減速機配0.37KW電機參數

R57F減速機配0.55KW電機參數

R57F減速機配0.75KW電機參數

R57F減速機配1.1KW電機參數

R57F減速機配1.5KW電機參數

R57F減速機配2.2KW電機參數

R57F減速機配3KW電機參數

R57F減速機配4KW電機參數

R57F減速機配5.5KW電機參數

R57F減速機配7.5KW電機參數

R58減速機生產工廠展示：看廠請聯(lián)系微信13827261050，獲取位置，需提前一天預約

推薦類似型號：R48減速機
